camden cx trk 2450 – transformer 24vac 40va + ac dc rectifier combo kit

Camden CX-TRK-2450 – Transformer 24VAC 40VA + AC-DC rectifier combo kit

$25.00

Transformer 24VAC 40VA + AC-DC rectifier combo kit Variant record generated from manufacturer nomenclature (https://www.camdencontrols.com/products/Transformers); price inherited from product #3076 pending owner confirmation.

SKU: CX-TRK-2450
Category: ,
Brands:

Description

Transformer 24VAC 40VA + AC-DC rectifier combo kit Variant record generated from manufacturer nomenclature (https://www.camdencontrols.com/products/Transformers); price inherited from product #3076 pending owner confirmation.

Reviews

There are no reviews yet.

Be the first to review “Camden CX-TRK-2450 – Transformer 24VAC 40VA + AC-DC rectifier combo kit”

Your email address will not be published. Required fields are marked *

Product specifications
Low-voltage wiring Required
BasisStructured, independently qualified product connection evidence
ElectricalThe kit manual connects rectifier red positive to the DC device positive and rectifier black negative to device ground. A direct external low-voltage DC load circuit uses two field conductors. The white and black AC leads connect between rectifier AC terminals and transformer secondary without polarity; these local assembly links do not establish external cable runs. The output is unfiltered and unregulated with AC ripple and may be unsuitable for electronics needing clean power. The manual describes approximately24VDC2A from a24V50VA transformer, but the product table lists24VAC40VA; confirm the delivered kit rating and load compatibility. The manual primary connection says110VAC whereas the general sheet says120VAC60Hz; use confirmed nameplate instructions. Field cable type, gauge, routing and physical run quantities remain unspecified.
Electrical wiring requiredYes
Conditional connectionsCX-TRK-2450 external DC load output: cable runs quantity unspecified; 2 conductor(s); wire type not documented; size unspecified; shielding unspecified; rating Type, gauge, shielding and physical run quantity selected by installation design.; endpoints Rectifier red positive and black DC negative to Selected compatible external DC load; when Installation configuration is Direct DC load connection after actual kit rating and load ripple tolerance are confirmed; internal AC links and mains primary are separate.
